1777073
Manufacturer:
Phoenix Contact
Mfr.Part #:
1777073
Datasheet:
Description:
Terminal Blocks Through Hole 2 5.08 mm 12 A 300 V
| Parameter | Value |
|---|---|
| Termination | Solder |
| Packaging | Bulk |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Voltage | 250 V |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Copper Alloy |
| Pitch | 5.08 mm |
| Current Rating | 12 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Straight |
| Color | Green |
| Gender | Male |
| Number of Contacts | 2 |
| Mounting Style | Through Hole, Vertical |
| lead free status | Lead Free |
| rohs status | Compliant |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Plastic |
| size width | 8.60 mm |
| size length | 20.3 mm |
| size height | 12.0 mm |
| Housing Color | Green |
| pin pitch | 5.08 mm |
| Connection Method | Plug |
| Current Rating (IEC) | 12 A |
| Voltage Rating (IEC) | 250 V |
Stock: 188
Distributors
pcbx
pcbxUnit Price$1.20605
Ext.Price$1.20605
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.20605 | $1.20605 |
| 10 | $1.02000 | $10.20000 |
| 25 | $0.96819 | $24.20475 |
| 50 | $0.91901 | $45.95050 |
| 100 | $0.87233 | $87.23300 |
| 300 | $0.82802 | $248.40600 |
| 500 | $0.78599 | $392.99500 |
| 1000 | $0.75689 | $756.89000 |
